Intellinet Low-Profile 19" Wall Mount Cabinet with 4U Horizontal and 2U Vertical Rails Slim, Space-saving Enclosure with Only 170 mm (6.7 in.) Depth, Ideal for AV, Multimedia and Surveillance Applications, Assembled, Gray RAL 7035

Code:713641

Overview

Slim, space-saving wall-mount network enclosure rack for AV multimedia equipment and more
The Low-Profile 19" Wall Mount Cabinet with 4U Horizontal and 2U Vertical Rails from Intellinet Network Solutions is a slim rack enclosure for residential and SOHO environments. It organizes and secures network equipment from multimedia, surveillance, audio/video and home automation while saving valuable space with its hybrid of two mounting options.

Thanks to its compact depth, it only extends 170 mm (6.7 in.) from the wall, but its vertical mounting option means you can install even bulky equipment like network switches with a depth up to 280 mm (11 in.). The sturdy IP20-rated steel housing with antistatic powder coating can be locked with a secure three-point door lock to prevent damage, tampering or theft. It carries a load capacity up to 60 kg (132 lbs.), and ventilation slots ensure maximum airflow to keep your equipment cool. Your structured cabling can enter through pre-punched holes on the top, rear or bottom. Its fully assembled shipping condition saves you the trouble of putting it together.

  • Information

    Slim, space-saving wall-mount network enclosure rack for AV multimedia equipment and more
    The Low-Profile 19" Wall Mount Cabinet with 4U Horizontal and 2U Vertical Rails from Intellinet Network Solutions is a slim rack enclosure for residential and SOHO environments. It organizes and secures network equipment from multimedia, surveillance, audio/video and home automation while saving valuable space with its hybrid of two mounting options.

    Thanks to its compact depth, it only extends 170 mm (6.7 in.) from the wall, but its vertical mounting option means you can install even bulky equipment like network switches with a depth up to 280 mm (11 in.). The sturdy IP20-rated steel housing with antistatic powder coating can be locked with a secure three-point door lock to prevent damage, tampering or theft. It carries a load capacity up to 60 kg (132 lbs.), and ventilation slots ensure maximum airflow to keep your equipment cool. Your structured cabling can enter through pre-punched holes on the top, rear or bottom. Its fully assembled shipping condition saves you the trouble of putting it together.

  • Specification

    Weight & dimensions
    Package depth555 mm
    Package width545 mm
    Package height205 mm
    Width550 mm
    Depth170 mm
    Height540 mm
    Weight8.5 kg
    Maximum weight capacity60 kg
    Packaging content
    Nuts includedYes
    Number of nuts12
    Screws includedYes
    Number of screws12
    Number of washers included12
    Features
    Key lockYes
    Frame typeClosed
    Product design4-post
    Rack capacity2U/4U
    International Protection (IP) codeIP20
    Front door constructionSteel
    Front door key lockYes
    TypeWall mounted rack
    Maximum weight capacity60 kg
    MaterialSteel
    Product colourGrey
    Ventilation holesYes
    Packaging data
    Nuts includedYes
    Number of nuts12
    Package depth555 mm
    Package width545 mm
    Package height205 mm
    Screws includedYes
    Number of screws12
    Number of washers included12
    Technical details
    Package width545 mm
    Package height205 mm
    TypeWall mounted rack
    Sustainability complianceYes
    Compliance certificatesRoHS
    Rack capacity2U/4U
    International Protection (IP) codeIP20
    Colour
    Product colourGrey
    Material
    MaterialSteel
    Logistics data
    Master (outer) case width560 mm
    Master (outer) case length560 mm
    Master (outer) case height190 mm
    Master (outer) case gross weight9.5 kg
    Products per master (outer) case1 pc(s)
